Power range: 1.5-5.5kW
Max DC input volt: 800Vdc
MPPT volt range: 150-800Vdc
Control mode: MPPTAutomatic tracking
Rated output volt: 3 Phase 380V
Protection class: IP20
Cooling mode: Nature cooling
Selection steps
1. Confirm head and flow: Vertical distance between pump position and water outlet is the head, flow is daily water consumption.
2. Confirm pump power: According to the head and flow.
3. Determine inverter model: According to the pump power.
4. Determine solar panel: Solar panel power is equal to the pump power in general application, 1.2--1.5 times the pump power if particularly large water consumption
