Application:
Widely used for 15MW-60MW power plants,10KV-500KV power substations,national grid,thermal power plant,hydropower station,telecom,railway,financial industry,military,oil and gas, substations for circuit breaker closing,two loop control,signal, protection,remote communication,electric power, petroleum,chemical,metallurgy,machinery,papermaking,coal,building materials,textile,wine,ect.
Features:
With high efficiency,high power density, high reliability,intelligent control,small size and light weight
With intelligent high frequency switching mode rectifier modules are adopted
With 48V,110V,125V,220V variety of options, which has all standard RS485 communication interface and several communication protocols.
The charging modules can work in parallel, N+1 hot swappable, high current share capability, flexible configuration
Intelligent monitoring function, LCD display, audible and visual alarm, perfect records function
With phase lack protection,delay protection when AC input switch and ensure soft start of charging module
Intelligent battery management and service, monitor terminal voltage, charging and dischaging current, test and record discharge capacity
With temperature compensation function, efficiency upto 95%
AC input voltage: 220VAC/1phase, 208VAC/220VAC/380VAC/400VAC/415VAC/460VAC/480VAC/3phases/40Hz to 70Hz
Output current from 10A to 600A, battery capacity range from 10AH to 3000AH, VRLA batteries and nickel cadmium batteries,ect
Insulation resistance is 20M ohm; Insulation strength of 2.5KVAC for 1minute;
Altitude less than 2000M, earthquake intensity less than 7
Modular design, with N+1 redundancy function, hot swappable,current sharing;Size:800x600x2260mm
