| Model | TC-LFP4822 | TC-LFP4850 | TC-LFP48100 | TC-LFP48155 | TC-LFP48200 |
| Rated Voltage [V] | 48V | 48V | 48V | 48V | 48V |
| Rated Capacity [Ah] | [email?protected] | [email?protected] | [email?protected] | [email?protected] | [email?protected] |
| Total Energy [Wh] | 1.06KWH | 2.40KWH | 4.80KWH | 7.44KWH | 9.60KWH |
| Inner Resistance [mΩ] | ≤100mΩ | ≤100mΩ | ≤100mΩ | ≤100mΩ | ≤100mΩ |
| Charge Voltage [V] | 54.75±0.2V | 54.75±0.2V | 54.75±0.2V | 54.75±0.2V | 54.75±0.2V |
| Max. Charge Current [A] | 22A | 50A | 100A | 100A | 100A |
| Recommend Charge Current [A] | 4.4~6.6A | 10~15A | 20~30A | 20~30A | 20~30A |
| Continuous Discharge current [A] | 22A | 50A | 100A | 100A | 100A |
| Peak Discharge current [A] | 44A(3S) | 100A(3S) | 200A(3S) | 200A(3S) | 200A(3S) |
| Dimensions [L*W*H, mm] | 482*328Depth*88[2U] | 482*360Depth*132[3U] | 482*460Depth*177[4U] | 482*465Depth*198[4U] | 482*530Depth*215[5U] |
| Weight [kg] | 18 | 33 | 45 | 65 | 85 |
| Cycle | >4500 cycles | ||||
| IP Class | IP55 | ||||
| Charge Operating Temperature [°C] | 0°C~45°C | ||||
| Discharge Operating Temperature [°C] | -20°C~60°C | ||||
| Relative Humidity | 20%RH-80%RH | ||||
| Communication Port | RS485, RS232, CAN | ||||
| Certification | CE, IEC62619, UN38.3, RoHS | ||||
