With the pure sine wave output, no matter coffee machine, microwave, TV, satellite, printer, or other equipment, the CPT inverter charger gives the perfect performance for running loads from household appliances to office devices.
Lithium battery compatibility gives another option for the house battery. Batteries are charged quickly and safely by the input utility power or vehicle generator. The automatic protect function ensures the battery banks from being over-discharged/charged. The CPT inverter charger guarantees the interrupted power supply with an auto transfer switch.
Product Features● Approved by ETL under UL458 and CSA C22.2, CE under EN55022:2006+A1:2007 standards● Pure sine wave output runs all loads from households appliances to office equipment● Built-in three-stage battery charger with the compatibility of Lithium/Gel/AGM/Wet battery recharges most batteries quickly while preventing them from being overcharged● Internal transfer switch transfers between DC power and utility power● External LCD remote controller-PTM12 or re-programmable interactive monitor control system-CR80 for easy data read and better references● Gen starter gives boost signal to start back up generator for emergency● Tool-free battery connection terminal for easy installation and DC short-circuit defending● 18 months warrantyProtection● Input AC over-voltage and low voltage protection ● Battery DC over voltage and low voltage protection● Short circuit protection● Over temperature protection● Overload protection
| Models | CPT6000 |
| output power | 6000W |
| SurgePower | 18000W |
| DCInputVoltage | 24VDC/48VDC |
| OutputVoltage | 100/110/120VAC±5%;220/230/240VAC±3%; 120/240VACSplitphase |
| OutputFrequency | 50/60Hz±0.5% |
| OutputWaveform | pure sinewave(THD<5%) |
| Idleconsumption(Savingmodel/workingmodel) | 9W/30W |
| AC input frequency | 50/60Hz±0.5% |
| Efficiency | 110VAC | 86% |
| 230VAC | 87% |
| transfer time | <8ms |
| ACInputRange | 90~135VAC/190~245VAC |
| DCVoltageRange | 20.0-31.0/42.0-62.0VDC |
| ACCharger/Bypass |
| DCoutputvoltage | Bulk(13.0-14.9V);Absorption(14.9-15.1V); Floatcharge(13.3-13.8V)(24V*2,48V*4) |
| Overcharge protection | 15.7VDC(24V*2,48V*4) |
| Chargecurrent | 110VAC | 75A/50A |
| 230VAC | 75A/50A |
| Transfer time | <10ms |
| Inputwaveform | Puresinewave(Utilitypowerorgenerator) |
| MAXbypasscurrent | 40A |
| Control&Signal |
| LEDindicator | 7-ledforworkingmode |
| Remotecontrol(optional) | CR10;PTM-12 |
| Dipswitch | Chargecurrent;Outputfrequency;ACoutputvoltage;DC/ACpriority |
| Networkfunction | Stand-alone,orTCP/IPoptional |
| Batterytype | Lithium,Gel,AGM,Wetorcustomized |
| Drycontactterminal | Byrelay |
| GeneralSpecification |
| Safety | UL458,LVD(EN60950) |
| EMC | FCCpart15ClassA,CE(EN55022:2006+A1:2007) |
| Operating/Storagetemp | -20-50℃/-30-70℃ |
| Working humidity | -20-90%RH |
| Weight(Kg/Ib) | 45/99 |
| Dimension(mm/inch) | 650*250*185/26*10*7 |
| Application | The vehicle, Yacht, Solarpowersystems, Portableequipment, Powertools, HomeandOfficeappliances |
