Rated energy(kWh)
|
14.336KWh
|
|
|
Configuration
|
1P16S
|
|
|
Nominal Voltage(V)
|
51.2V
|
|
|
Working Voltage(V)
|
42V~58.4V
|
|
|
Nominal Capacity(Ah)
|
280Ah
|
|
|
Rated charge/discharge Current(A)
|
100A @25± 2℃
|
|
|
Maximum charging current
|
200A@25± 2℃
|
|
|
Maximum discharge current
|
200A @25± 2℃
|
|
|
Working Temperature
|
0-40℃(Charge) -20-40℃(Discharge)
|
|
|
Humidity(%)
|
5~80%
|
|
|
Altitude Limited(m)
|
0-3000m
|
|
|
Weight(Kg)
|
113Kg± 3kg
|
|
|
Dimension(mm)
|
817×412×267mm
|
|
|
Storage temperature and humidity
|
-10℃~35℃ (Within one month of storage) 25± 2℃(Within three months of storage) 65%±20% RH
|
|
|
cycle life
|
6000 cycles @25℃ 100ACharge and discharge current 80%DOD
|
|
|
IP grade
|
IP20
|
|
