Product Advantage
Engineered to optimize energy output, the BMS Parallel Box-II G2 effortlessly expands battery capacity and prolongs battery lifespan. By supporting parallel connection of two battery strings, it enhances ESS (Energy Storage System) performance with greater operating efficiency and longer runtime.
Reliable Performance
- Easily expand capacity
- Extend battery lifespan
Flexible Adaptability
- Support two-column parallel connection
- Support T-BAT-SYS-HV-3.0, T-BAT-SYS-HV-5.8
Product Parameters
| Dimensions (W x H x D) | 368 x 334 x 153.5 mm |
| Weight | 8.7 kg |
| Expected life | 5 years |
| Protection | IP65 |
| Input / Output voltage range | 70 ~ 550 V |
| Standard power | 11.5 kW |
| Maximum power | 16.1 kW |
| Safety | IEC / EN 62477-1, IEC / EN 61439-1, IEC / EN 61439-2 |
| EMC | EN 61000-6-1 / 2 / 3 /4 |
