Oringinal integrating traditional cell cabinet and power cabinet, the industry-origin applies highly stable temperature control technology in batch to charging/discharging equipment, successfully addressing pain points such as large equipment footprint, long installation cycles, low charging/discharging efficiency, and poor cell temperature uniformity. This not only improves cell quality consistency but also achieves dual cost reduction for both equipment and factory building.
Equipment Advantages
Space-saving
22% reduction in equipment footprint, with built-in maintenance platform
Low energy consumption
36% energy savings, for a 280Ah-line with annual production of 5GWh, the annual electricity savings for the grading segment are approximately 1.87 million yuan (compared to parallel split cabinets)
Improving cell consistency
Cell temperature uniformity: ±2°C, temperature rise < 10°C, 33% improvement in cell consistency
High installation efficiency
Avoiding on-site wiring works
Key Features
Automatic calibration design
Modular pull-out design of probe board, no cables attached, easy for maintenance
Improvement of equipment system efficiency and commissioning efficiency
Using water to control the temperature, with high-precision temperature acquisition technology, resulting better chamber temperature uniformity
Anomaly detection (polarity/tab contact resistance/loop contacting resistance/ambient temperature/channel temperature/smoke/power shut-off protection)
Standard configuration
Water-cooling temperature control system
Modular pull-out probe board
High precision adjustable smoke sensor
Low impedance, heat-resistant and high-current resistant knurling probe Triple security protection: modular level, process level and system level
Benefits of the Product
Water&gas integrated fire-suppression system
Capacity compensation based on temperature
Automatic wireless power module calibration tooling/Automatic positioning tooling/Cable&wires sequence detection tooling
