| ? Non-polarity design, 1P~4P | ? TUV, CE, CB, UL, SAA certified |
| ? The electrical life can reach 1500 times | ? Ics≥6KA |
| ? 30'℃ ~+70'℃, Meet ROHS and REACH environmental protection regulations | |
 |  |  |
| Full current specification | High breaking capacity | Non-polar design |
 |  |  |
| Adapt to high and low temperature environment | Long mechanical and electrical life | Flame retardant material, more secure |
 | ||
| UL Listed |
| Rated current | 16A,20A,25A,32A,40A,50A,63A,80A | Insulation Voltage | 1000V | Withstand impulse voltage | 6kV |
| Rated working voltage | 500VDC/2P,750VDC/3P,1000VDC/4P | Tripping Characteristics | B,C | Ambient Temperature | -30℃~+70℃ |
| Breaking capacity | 10kA | Mechanical life | 20000 times | Electrical life | 1500 times |
| According to | UL 489 and CSA C22.2 No.5 |
