High-speed operation: High processing capability with precise data sampling; features a dual 32-bit CPU structure and 16-bit A/D chip.
Strong electromagnetic compatibility and anti-interference: Designed with a plug-in structure, strong and weak current separation, resistance to strong vibrations, and strong interference design.
Operating temperature: -10°C to +55°C
Storage and transport temperature: -25°C to +70°C
Relative humidity: No more than 90%, non-condensing
Atmospheric pressure: 80 to 110 kPa
Rich interfaces and flexible expansion: 16 high-precision analog sampling channels, 32 digital sampling channels, and 16 programmable output relay.
Self-diagnostic warning system for safety and reliability: Embedded timed hardware self-check function, capable of saving 1000 event records and 10 fault waveforms without power.
Supports online configuration interface: Online language switching among three languages, SNTP network time synchronization, IRIG-B time synchronization, and communication protocols including MODBUS/RTU, MODBUS/TCP, IEC61850/MMS.
