| ? 1500V,63A,1~10 Strings models for option | ? Complies with TUV, CE, CB, SAA, UL certification |
| ? Meet V0 flame retardant grade anti-UV F1 grade | ? IP65 design, Optional anti-PIL |
Max 1500V / Max 50A |
Arc Fault protection (Optional) |
PID recovery (Optional) |
Flame retardant UL94-V0 |
Easy Installation |
Physical Isolation |
Outdoor Installation IP65 |
Over temperature protection > 70℃ |
FB1 FB2 function achieves external monitoring | |
| PV System Voltage | ≤1500V | AC Input Voltage Range | 100Vac - 270Vac | Short-Term Power Consumption | 14W |
| Electrical Life | >1500 times | PID Recovery Voltage to Earth at night | +600V | PID Recovery Current Output at night | 6.7mA |
| System Insulating Impendance | >200kΩ | Module Type Required | P Crystalline Silicon Type |
