Key Features
• Multi-energy complementarity
Efficient integration and utilization of various energy sources, including the power grid, photovoltaic energy, energy storage, and diesel generators, to optimize energy efficiency.
• High reliability
Supports seamless switching to ensure uninterrupted power supply during sudden outages. Multiple energy sources serve as backups for each other, further enhancing power supply reliability.
• Flexible scalability
Uses standardized battery cabinets and MPPT modules (Maximum Power Point Tracking) in a modular structure, making it possible to flexibly adapt to different scale applications.
• Safety system
Integrated multi-level alarms (gas/water fire alarms) to ensure the safety of your installation.
Basic Parameters
• Battery DC input voltage range
728V - 936V
• Battery cabinet energy (simple)
261kWh
• Rated AC voltage
400V
• Rated AC power
125kVA/250kVA/500kVA
• Rated output current
182A/364A/728A
• Built-in isolation transformer
Yes
• Diesel generator connection
Yes
• IP rating
IP20/IP54
• Switchgear cooling process
Smart air cooling
• Battery cabinet cooling process
Smart liquid cooling
Where you need it
• Backup power
• Microgrid
• High-quality scissors
• Current quality control
