The Gateway BDG-256, them you save money on your electricity bill and contribute to a cleaner future.
Dimensions: 6.69” x 4.33” x 1.46”?
Weight: 5.29 oz
| Model | BDG-256 |
|---|---|
| Communication interface | |
| Communication with the microinverter | AC power line communication |
| Ethernet | 10/100 Auto Detect, Auto Negotiation |
| USB | USB 2.0 interface, auto-detection, auto-negotiation |
| Wi-Fi | Support (accessory required) |
| Monitoring capacity | 255 micro inverters (depending on interference on power grid) |
| Human interface | |
| Display | LCD touch screen |
| Power supply requirement? | |
| Alternating current supply | 100- 240 Vac, 50/60 Hz, 60mA |
| Consumed potence | 3.5 watts Maximum |
| Mechanical data | |
| Dimensions (LxWxH) | 6.69” x 4.33” x 1.46” (170 mm x 110mm x 37mm) |
| Weight | 5.29 oz (150g) |
| Ambient temperature range | -40 ?C a +55 ?C (-40 ? a 131 ?F) -40 ?C a +49 ?C (-40 ? a 120 ?F) if installed in an enclosure |
| Cooling | Natural convection |
| Environmental Rating | IP30. For installation indoors or in an NRTL-certified, NEMA type 3R enclosure. |
| Other features | |
| Standard warranty period | 1 year |
| Certifications | UL 60950-1 2a edition Rev December 19, 2011 CSA C22.2 2a edition Rev December 19, 2011 FCC Part 15 Class B AS / NZS 60950.1: 2011 Inc A1 AS/NZS CISPR 22: 2009+A1:2010 EN 60950-1:2006+A11:2009+A1:2010+A12:2011 EN 55022:2010 EN 61000-3-2:2006+A1:2009+A2:2009 EN 61000-3-3:2008 EN 55024:2010 Directive EMC 2004/108 / CE |
