1, 2, 4, 8 blocks can be con?gured arbitrarily
Supports “side by side, back to back” parallel arrangement
24 tons module, supports maritime, land, and railway transportation
Flexible supplement, low replacement cost
RTE ≥ 93%@4h, 690Vac
New self-developed SIC PCS with max 99.3% ef?ciency
Dual-channel liquid-cooled TMS for batteries and PCS, decreasing 20% energy consumption
>10000 cycles@SoH70%, 0.5P
Full-time balancing technology, improving lifecycle discharge capacity by more than 2%
Intelligent TMS and dynamic temperature control algorithm realize the reliable guarantee of battery life
Support Grid-forming, Grid-following, Black Start and islanding protection, etc
Comprehensive safety protection design, to achieve full coverage of all scenarios
AI-based technology enables thermal runaway early warning 7 days in advance
The maximum thermal runaway loss reduced from 20HC to 10HC
Provide AI-based intelligent platform, conduct more than 10 types of O&M work online and offline
The O&M work assistant HyperGenie is constructed to realize intelligent guidance functions, reducing the difficulty and workload on site
