Model
|
NE-5600
|
NE-11200
|
NE-16800
|
||
|
Output Power Range
|
5.6KW
|
11.2KW
|
16.8KW
|
||
|
Energy Storage Capacity(KWh)
|
5.12-30.72
|
10.24-30.72
|
15.36-30.72
|
||
|
Rated Grid Output Current
|
25.5A
|
51A
|
76.5A
|
||
|
Rated AC Voltage
|
220V/230Vac
|
|
|
||
|
Inverter Weight
|
20KG-60KG
|
|
|
||
|
Battery Pack Weight
|
55KG-330KG
|
|
|
||
|
Noise Level
|
≤60dB
|
|
|
||
|
Relative Humidity
|
5% to 90%
|
|
|
||
|
Protection Grade
|
IP54
|
|
|
||
|
Communicate
|
RS485/WiFi/GPRS
|
|
|
||
|
Battery Type
|
LiFePO4
|
|
|
||
|
Battery Pack Size
|
200mm*400mm*600mm(W*T*H)
|
|
|
||
|
Inverter Size
|
200mm*400mm*600mm(W*T*H)
|
|
|
||
|
Cycle Times
|
8000+ Cycles,10 Years DesignLife Time
|
|
|
||
