Key Features
Safe and Reliable
The LiFePO4 battery offers up to 6000 cycles for extended performance.
Flexible and Scalable
Up to 15 devices can be connected in parallel to achieve a maximum capacity of 76.8 kWh.
Dependable Performance
Protection class IP65, designed for use in harsh environments.
Easy Installation
Supports both floor-standing and wall-mounted installations.
Intelligent Control
Use your smartphone to freely manage your home's energy supply.
Fundamental Parameters
- Cell Technology: LFP (LiFePO4)
- Usable Battery Energy: 5.120 kWh
- Nominal Voltage: 51.2 V
- Operating Voltage: 44.8 ~ 56.16 V
- Maximum Charge and Discharge Current: 100 A
- Weight: 48.8 kg (107.5 lbs)
- Dimensions (W×D×H): 470×160×635 mm (18.5×6.3×25 in)
- Cycle Life: 6000 cycles or ten (10) years at 80% DOD / 25 °C / 0.5 C, 70% EOL
- Ingress Protection: IP65
- Compliance: UN38.3 / IEC62619 / IEC61000 / IEC62040-1 / FCC / UL1973 / UL9540A
Intelligent Control and Monitoring
Multiple operating modes to optimize energy consumption based on real-time conditions. Remote real-time monitoring functions via Wi-Fi/Bluetooth for easy monitoring and operation.
