Technical Data
| Product name: Diesel generator set |
Model: WCFJ15 |
Spec: 17KVA |
| Pro.ID: P02004 |
Voltage： 3P 380V 50Hz |
Type： Open marine generator set |
Technical data table:
| NO. |
Technical data |
Parameter data |
Remarks |
| 1 |
Max Power |
13.2KW |
|
| 2 |
Rated Power |
12KW |
|
| 3 |
Rated speed |
1500rpm |
|
| 4 |
Governor |
Mechanical |
|
| 5 |
Starting method |
Electrical |
|
| 6 |
Alternator Power Factor |
0.8 |
|
| 7 |
Protection Class |
IP23 |
|
| 8 |
Insulation Class |
F |
|
| 9 |
Rated Current(A) |
24.7A |
|
Product configuration table:
| NO. |
Part name |
Brand |
Model |
Remarks |
| 1 |
Engine Model |
Weichai |
WP2.3C25E200 |
|
| 2 |
Alternator |
Siemens |
|
|
| 3 |
Controller |
CSCPOWER |
|
|
| 4 |
Starting method |
CSCPOWER |
Electrical start |
|
