NFPV-32 20A 1000v Solar photovoltaic fuse
Application
NFPV-32 Fuse was designed and manufactured , complying with the standard IEC60269-6 The Rated Current up to 30A,rated voltage up to 1000V DC. It applied for PV DC combiner box, inverter etc, with the main function of over-current protection and effective disconnection.
A range of 10×38mm fuse links specifically designed for protecting photovoltaic strings. These fuse links are capable of interrupting low overcurrents associated with faulted photovoltaic string arrays(reverse current, multi-array fault).
Parmeter
Dimensions
…
