| ? Compatible with all brands inverters | ? Slim design, easy installation |
| ? Max input: 20A, 80V/120V, fits to mainstream solar panels requirement | ? Separate line control, no interference from other sources |
| ? No cross-talking issue, making the site cable layout much easier | ? 25 years lifespan, 12 years warranty, cost-effective |
| ? Flame retardant UL94-V0 | ? Certified, including CE, UL 1741 & UL 3741 |
| ? Unique temperature sensing technology, automatic shutdown when the temperature reaching to 85℃ | |
| Product Model | PEFS-PL80S-11 | PEFS-PL80S-21 | PEFS-PL120S-11 | PEFS-PL120S-21 |
| Max Input Voltage | 80V | 80V | 120V | 120V |
| Max Output Voltage | 80V | 160V | 120V | 240V |
| RSD VS module(s) | 1:1 | 1:2 | 1:2 | 1:4 |
| Max Input current | 20A | 20A | 20A | 20A |
| Max Output current | 20A | 20A | 20A | 20A |
| Power consumption | 0.6W~0.8W | 1.2W~1.6W | 0.6W~0.8W | 1.2W~1.6W |
