Specification:Insulation material ............................................PPE/PA
Fuse Specification..............................................1A-50A
Rated current（Without fuse）..........................50A
Safety degree .......................................................II
Rated voltage ......................................................1500VDC
Flame class ............................................................UL94-V0
Test voltage ..........................................................8kV(50Hz,Imin)
Insertion force/Withdrawal force .........................≤50N / ≥50N
Contact resistance ..............................................＜ 0.25 mΩ
Ambient temperature range.................................-40℃…+85℃(IEC)
Contact material....................................................Copper,Tin plated
Upper limiting temperature ...............................110℃(IEC)
Degree of protection ...........................................IP68
Suitable cable cross sections ............................2.5~10mm2 /14~8AWG
Rated Impulse voltage..........................................12KV
Suitable for fuse size(mm) ..................................10*85 / 14*85
Advantage:Simple, quick installation
Standard module design, assembled discretionarily
With the capacity of anti-aging and anti-ultraviolet radiation
Meet the requirement of outdoor condition
