Product overview
MS40K/T Multi Busbar PV Cell Soldering Stringer is a fully automatic machine, which can be used with different types of silicon solar cells, monocrystalline or polycrystalline, and solder them into a string. It is suitable for traditional 156/182/210 3BB~12BB cells, and 230/3BB~12BB cells (after upgrading). With the use of PLC, servo, SCARA robot, industrial image processor system and other advanced automation technology, all processes from cell feed to string outlet are automated without manual operation. The designed capacity of this equipment is up to 4000 cells per hour. (Refer to Section 7.1 Acceptance Criteria for actual capacity.)
MS100B MBB PV Cell Soldering Stringer is a fully automatic machine used to solder the mono-Si or poly-Si cells into a string. It can work with 156-220 (3BB-15BB) cells or 156-220 (full, half-cut or 1/3-cut) cells after upgrade. With the use of PLC, servo, SCARA robot, industrial image processor system and other advanced automation technology, the entire process from cell feed to string outlet is fully automated.
