Solar inverter to run 110Vac-120Vac 1HP/750W Pump by Solar Panels?only or called solar pump controller, solar drive, which is input solar panels to run 110V AC pumps directly under sunshine.?The direct current generated by solar modules is input to the inverter and then converted into the alternating current to drive various pumps directly,no need battery. Additionally, the output frequency is adjustable in real time according to sunlight intensity change.
The solar pump inverter 110Vac could configure fully automatic system compatible with AC, single phase or 3-phase, submersible and surface mount pumps, and high efficiency PMSM Pumps. The system is composed of PV generator solar panels, a pump and the solar pump inverter. Based on the design philosophy that it is more efficient to store water rather than electricity, there is no energy storing device such as storage battery in the system. The system is prepared to be combined with a elevated water storage, e.g. water tower or an uphill tank installation.?Within VFD and MPPT technologies, and flexible settings design, the inverters are ideal choose for any AC 110Vac solar pumping system?Its price is best with robust quality!?Cost-effective for deep well pumping, farm irrigation,?solar pumping system?run by solar power directly! Now GPRS online monitoring and AC & DC inputs running together synchronously are available! You also can choose our extra IP54 weather-proof case(extra price) for the inverter with?anti-dust screen, PG4 Connectors, DC breaker, AC breaker, terminal bars etc!
CVT & Real MPPT: widely adjustable settable MPPT(Maximum Power Point Tracking)?voltage and MPPT?stride,?ensure that you get the most power output from your solar panel and maximizes the performance of your pump all the day.to make best solar pumping system for specific solar panels configuration and sunshine condition!
Metering: Built-in flow measurement and sensorless flow calculation. And easy to get how much energy generated by this system with generated energy and calculating. 2. Connect output U, V, W terminals of the solar pump inverter to 3phase AC pumps(Any two of U V W to Single AC pumps) 3.Connect water level sensor to the inverter if needed 4.Connect GPRS module(optional) if need remote online monitoring. You also can get all parts of 1HP 110Vac-120Vac solar pumping system?from our store, like solar panels, solar module mounting systems, cables, etc.?
Auto or Manual: Defaulted automatically running or stop according to solar radiation, or start&stop it by manual or extra switch/water level sensor.?Compatible with all pump types!
Full Protection:Overloading, over-voltage, low voltage, over current, short-circuit, over heat, grounding/Earth, phase-lose, dry-protection,motor locked, Open motor circuit, weak sunlight, water level sensor compatible. Protect pump motor at best.
So Easy to use:
1. Connect Positive and Negative terminals of Solar panels arrays (which should be total 1.2-1.5times than pump power,and total Voc
How much cost could it save for you than diesel? Find Comparison Data with?diesel powered pumping on our Blogs here!
