IP65 Solar Pump Inverter CHP6-7R5 10HP/7.5KW 3Phase 380Vac, or called solar MPPT pumping controller, solar driver, which is input solar panels to run AC pumps directly under sunshine. Within VFD and MPPT technologies, the inverters are ideal choose for any single phase or 3 Phase AC pumps for deep well pumping, farm irrigation, water supply run by solar power directly! CHP6 Series is IP65 weather-proof for outdoor installation, robust even under hash environment like desert! Lifespan is 10years! And built-in MC4 connectors/PV switch/fuses/surge protectors/PV booster(1-2.2kw)/MPPT circuit/breakers/optional GPRS!
Real MPPT: MPPT circuit by both hardware and algorithm, higher accuracy, easy to configure with solar panels.
Auto or Manual: Defaulted automatically running or stop according to solar power, or start&stop it by manual or extra switch or water level sensor.
Full Protection:Overloading, over-voltage, low voltage, over current, short-circuit, over heat, grounding, phase-lose, dry-protection,motor locked, weak sunlight, water level sensor compatible.
