Technical Parameters |
|||
|
Model |
TTHC 48V |
TTHC 80V |
TTHC 96V |
|
System Input Characteristics |
|||
|
Ac Input Voltage |
380Vac/400Vac/480Vac |
||
|
Power Supply |
Three-phase four-wire (3P+PE)/Three-phase five-wire(3P+N+PE) |
||
|
Ac Network Frequency (HZ) |
50～60Hz |
||
|
Stand-by Power Consumption |
≤50W |
||
|
Leakage Current |
<3.5mA |
||
|
Start-Up Inrush Current |
Less than 10% of the rated input current |
||
|
System Output Characteristics |
|||
|
Output Voltage |
40Vdc~60Vdc |
40Vdc~100Vdc |
40Vdc~110Vdc |
|
Output Current Range |
5A~200A |
||
|
Output Power (kW) |
6kW~20kW |
||
|
Voltage Regulation Accuracy |
≤±0.5% |
||
|
Current Regulation Accuracy |
≤±1% |
||
|
Voltage Ripple |
≤±1% |
||
|
Efficiency |
≥93% |
||
|
Overload Capacity |
110% of rated power |
||
|
Communication Interfaces |
RS485 interface、CAN interface |
||
|
Protection Functions |
|||
|
Battery Reverse Polarity Protection |
Yes |
||
|
Output Short Circuit Protection |
Yes |
||
|
Output Overvoltage/Overcurrent Protection |
Yes |
||
|
Overtemperature Protection |
Output shuts down if internal temperature >65℃ |
||
|
Abnormal Protection |
Shuts down with no output if power device anomaly occurs |
||
|
Other Parameters |
|||
|
Protection Level |
IP20 |
||
|
Overvoltage Category |
OVC III |
||
|
Operating Temperature |
-20℃ to +65℃ (derated output from 45-65℃) |
||
|
Storage Temperature |
-40℃～+75℃ |
||
|
Relative Humidity |
5～95%, non-condensing |
||
|
Altitude |
Full load output up to 2000m |
||
|
Charger Dimensions |
600*450*600mm (L*W*H) |
||
|
Product Weight |
50kg |
||
|
Cooling Method |
Air cooling |
||
