Measurement of import and export active reactive and apparent power/energy
Instantaneous parameters of voltage current power maximum demand frequeny of each phase etc
Three different configurable harmonic measurement mode
Support up to 5 TOU configurable tariff with DST
Support 10 time divisions 8 day profiles 8 week profiles 2 season profiles and 50 special days
Support recording load profile up to 8832 entries with date and time
Record of active and reactive energy with configurable time interval
Supports two-way communication locally and remotely via different interfaces
Local communication(meter to local software or HHU) interfaces: optical RS485
Replaceable remote communication module(under terminal cover): PLC RF GPRS/3G/4G NB-IoT
Self-diagnostic alarm&tamper detection and notification
Capable to record various events log includes alarm events tamper events power quality events
Load switch on R S T phase for load management and remote control
Auxiliary 2 relay output and 2 relay input for external device
Configurable disconnection of inner relay upon meter abnormal tamper overload low voltage etc
Anti-tamper with events log include open meter cover open terminal cover current reverse bypass magnetic interference etc
Tamper elimination through pinhole press or remote clear tamper command by AMI system
