Summary
Upgrade your off-grid energy system with the 24V 8KW-11KW Waterproof Hybrid Solar Inverter by SUNNAL, featuring IP65 protection and dual outputs for versatile performance. This high-frequency inverter delivers pure sine wave output, ensuring compatibility with a wide range of devices. With built-in MPPT technology, it maximizes energy conversion efficiency, making it ideal for residential and small commercial applications. Perfect for users seeking a reliable and weather-resistant solution to manage their solar power systems effectively.More
Specifications
Application:
Hybrid Solar System
Inverter Type:
MPPT
Output Power:
8KW
11KW
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL
  • 24V 8KW-11KW Waterproof Hybrid Solar Inverter | IP65 Dual Outputs | Pure Sine Wave MPPT | SUNNAL

The SUNNAL 24V Hybrid Solar Inverter features a compact design (158.4 x 502.5 x 530.8mm) and weighs only 21kg, simplifying installation. It supports surge power up to 22000VA and a maximum PV array power of 8KW/11KW, certified with CE standards for safety and compliance. Suitable for both off-grid and hybrid applications, it offers flexibility and reliability. The intelligent control system enables real-time monitoring and adjustments, ensuring optimal performance. Perfect for homeowners and businesses aiming to reduce costs and improve energy independence with a high-efficiency inverter. Enhance your solar system with SUNNAL’s reliable hybrid inverter for optimal performance and durability.

Key attributes

Output Type
Single Phase
Inverter Efficiency
93%
Place of Origin
Jiangsu, China
Model Number
SNA-MAX-02
Brand Name
Sunnal
Input Voltage
230VAC
Output Voltage
230VAC±5%
Output Current
60A/80A
Output Frequency
50/60Hz
Size
158.4 x 502.5x 530.8mm
Type
DC/AC Inverters
Weight
21KG
Waveform
Pure Sine Wave
Surge power
22000VA
Overcharge Protection
66 VDC
Battery Voltage
48VDC
Maximum PV Array Power
8KW/11KW
MPPT Range @ Operating Voltage
90-450VDC
Maximum PV array open circuit voltage
500VDC
Maximum Solar Charge Current
150A
Max AC Charge Current
150A

Packaging and delivery

Selling Units
Single item
Single package size
19X50X51 cm
Single gross weight
21.000 KG
