Basic parameters of battery cells
|
|
| Nominal capacity Ah |
280
|
| Nominal energy wh | 896 |
| Nominal voltage V | 3.2 |
| Working voltage range V | 2.5~3.65 |
| Standard charging power w | 448（0.5P） |
| Standard discharge power w | 448（0.5P） |
| Maximum continuous charging power w | 896（1.0P） |
| Maximum continuous discharge power w | 896（1.0P） |
| Standard charging current A | 140 (0.5C) |
| Maximum continuous charging current A | 280 (1.0C) |
| Standard discharge current A | 140 (0.5C) |
| Maximum continuous discharge current A | 560 (2.0C) |
| Communication internal resistance ACIR m Ω | 0.16±0.1 |
| DC internal resistance DCIR m Ω | ≤0.6mΩ |
| cycle life | ≥8000次 |
| Cell size (T * W * H) mm | 71.6*174.2*207.3 |
| Cell weight kg | 5.5±0.3 |
